BEHATEST Megohmmeter

1kV Digital Insulation Tester/

Model: 92751

About Insulation:
Every electrical apparatus and installation need to be safe for the user and for the equipment itself.
Electrical conductors of electricity need to be insulated from each other, so that they do not create electrical hazard or unnecessary consumption.
Badly insulated circuits can create leakage current which can be dangerous and trip your RCD, GFCI, RCCB or ELCB.
Each country regulate those levels at which the insulation is acceptable.
Generally, Insulation resistance measurements are done between each conductor and the earth, and between each conductors.
About Continuity:
Checking the continuity of wires, complete circuits, connections, closure of contacts, circuit breakers, fuses, bounding resistance of connections, etc... Are all very important.

Features:
● 68 x 34mm (1.338" x 2.677") large LCD display.
● Three insulation test voltages (DC V) : 250V, 500V, 1000V.
● External voltage warning indication.
● Automatic circuit discharge.
● Test insulation at rated voltage into a 1mA load.
● 200mA resistance tests short circuit test current.
● AC voltage measurement.
● Fuse protection.
● Timer for test function (count 3~5 minutes).
● Data hold function.
● Auto power off function.
● IEC/EN 61010-1/ BS 16th edition/ CAT III 600V.

Display	3 1/2 digit; LCD; 1999 Digits
Insulation
Test Voltage	250V/500V/1000V
Auto-Ranges	0-20MΩ/0-200MΩ/0-2000MΩ
Accuracy	20MΩ: ±(1.5%rdg+5dgt) 200MΩ: ±(2.5%rdg+3dgt) 2000MΩ: ±(5%rdg+5dgt)
AC Voltage
Measuring Ranges/ Resolution	0-600V/1V
Line Frequency Range	40-120Hz
Accuracy	±(1.5%rdg+3dgt)
Continuity
Measuring Range(Auto)	0-20/0-200/0-2000Ω
Open Circuit Terminal Voltage	4V/DC
Shot Circuit Terminal Current	200mA/DC
Accuracy	±(1.5%rdg+3dgt)
Buzzer Sounds under	10MΩ
General
Power supply	6 x 1.5 V, IEC LR6
Safety complying with	IEC 61010/ BS 16th edition
Measurement category	CAT III/600 V
Dimension	205 x 90 x 55mm
Weight	approx. 550g (battery included)
